FBSimCity v0.4.0: the backup yard — gbak pins the OIT, nbackup fills the delta
FBSimCity, the explorable isometric city of Firebird internals, is at v0.4.0. This release adds a whole backup yard, built around what gbak and nbackup actually do.
gbak: the backup that pins your OIT
gbak takes a logical backup online: it attaches like any other client and reads every table through a snapshot transaction. That snapshot is the interesting part, because it pins the OIT for the entire run. Garbage collection stalls, cooperative GC refuses to demolish anything, and the record version towers climb until the backup finishes.
This is why a nightly gbak against a busy database and a mysteriously bloating database are so often the same story. Now you can watch it happen instead of inferring it from gstat -h: run the nightly gbak scenario.
nbackup and the difference file
nbackup is the other half: a physical backup, incremental by level. Level 0 copies the whole file, level 1 only the pages changed since level 0, and so on. The chain is enforced in the model just as it is in reality: ask for a level 1 without a level 0 and it refuses, and Restore chain reports which levels a restore would have to apply, in order. Lose level 0 and the rest are waste paper.
Locking the database with nbackup -L freezes the main file so it can be copied safely while the server keeps running. Every page written from that moment lands in the difference file instead, a new orange pit beside the main excavation that fills up visibly and merges back on unlock. Forget to unlock and it grows for as long as you watch: see a locked database filling its delta.
Dirty pages stopped being free
This release also fixes a genuine falsehood in the simulation. Evicting a dirty buffer used to cost nothing, which quietly understated write pressure. It now writes the page out first, so a reader that needs a frame pays for somebody else’s write.
The interesting part is what that does not cause. Because commits flush their page under forced writes, which is Firebird’s default, dirty evictions stay rare on a healthy database at around 1% of evictions, and only start biting when the cache is too small for the working set, reaching roughly 5% at 16 buffers. The honest lesson is “your cache is undersized”, not “writes are bad”, and the new evictions (dirty N) readout shows exactly that.
A knob audit
Since the whole point is intuition rather than emulation, v0.4.0 documents itself. docs/KNOBS.md lists every control and readout, what it does to the model, and whether the mechanism is real, merely scaled, or a plausible modeled stand-in, followed by the deliberate simplifications. Sweep here is time-triggered rather than transaction-gap-triggered; lock contention is a probability rather than a wait-for graph; no SQL is parsed at all. It is all in the table, so nobody has to discover it by reading the source.
Also in this release
- Subsystem controls now live on the subsystem: start a sweep from the GC depot, run backup levels or lock the database from the nbackup vault, forget to commit a transaction from the Transaction Hall.
- The screenshot driver no longer leaks browser profiles, and form controls are 16px so iOS Safari stops zooming the page.
City: mariuz.github.io/FBSimCity
Release notes: v0.4.0
Source: github.com/mariuz/FBSimCity (MIT, plain HTML and JavaScript, no build step)
Corrections are very welcome, especially on the backup mechanics, which I modeled from the documentation rather than from the engine source.
FBSimCity is an independent educational project, not affiliated with or endorsed by the Firebird Project. Firebird® is a registered trademark of the Firebird Foundation Incorporated.
